제품특징

- 정확한 비디오 도량형 - AcuCentric^® 모터 구동식 줌 렌즈가 각 줌 위치의 배율을 자동으로 보정합니다.
- 안정성과 정밀성- 무거운 주물 베이스와 Y축 중앙 드라이브가 내장된 복합 스테이지로 안정성을 제공합니다.
- 멀티센서 다기능성 - 터치 프로브, 레이저 및 마이크로프로브 옵션

 Standard

 X, Y, Z Travel

 450 x 450 x 200 mm

 X, Y, Z Scale Resolution

 0.1 µm

 Drive System

 DC servo with 4-axis control (X,Y,Z,zoom); with multifunction handheld controller

 Worktable

 Hardcoat anodized, with fixture holes, removable stage glass, 50 kg recommended max payload

 Rotary Axis

 Miniature Servo Rotary (MSR), MicroTheta Rotary (MTR)

 Optics^*

 AccuCentric^® auto-compensating zoom,

motorized;1.0x lens; 2.0x lens attachmnet; 1.0x adapter tube

 Focus Grid Projector: LED or Tungsten fiber-optic sources

 Laser Adapter: Allow for field retrofit of TTL Laser. Includes Laser Pointer

 Replacement Lenses: 1.0x Long Working Distance (LWD),2.5x 5.0x

 Laser Lenses: 2.0x (included with TTL Laser), 5.0x

 Lens Attachments for 1.0x Lens: 0.5x, 0.75x, 1.5x

 Factory Installed Adapter Tube: 0.67x, 2.0x

 FOV Range

 6.6 mm x 5.0 mm (no attachment, low zoom) to

 0.7 mm x 0.5 mm (2.0x lens attachment, high zoom)

 15.0 mm x 11.3 mm (0.67x tube, 1.0x lens, 0.5x attachment)

 to 0.13 mm x 0.10 mm (2.0x tube, 5x lens)

 Working Distance

 63 mm (no attachment)

 24 mm (2.0x lens attachment)

 Up to 98 mm (1.0x LWD, 0.5x attachment)

 Illumination

 Substage LED profile (green), coaxial LED surface (white), SmartRing LED ring light (white)

 High performance all green LED illumination, tungsten illumination for coaxial and ring light, infrared illumination for coaxial and ring light

Ring lights:VuLight™with multiple angles of incidence; Fiber Optic Ring mounted below, integrated with, or in lieu of SmartRing light

 Camera

Color digital metrology camera

 Image Processing

256 level grayscale processing with 10:1 subpixel resolution

 Sensor Options^**

Tactile:TP20 or TP200 Touch Probe, SP25 Scanning Probe, Feather Probe ™

 Non-Contact: DRS™ Laser, Through-the-Lens (TTL) Laser, Rainbow Probe™, TeleStar Probe

 Controller

 Windows^® based, with up-to date processor and on board networking/communication ports

 Controller Accessory Package

 24" flat panel, or dual 24" flat panel LCD monitors; keyboard, 3-button mouse(or user supplied)

 Software

 · Choice of ZONE3 Express or Meaure - X or MeasureMind 3D metrology software

 · QVI Portal

 Metrology software: ZONE3 Prime, ZONE3 Pro

 Productivity software:MeaureFit^® Plus, SmartFit^® 3D, SmartProfile^®, E-SPC

 Offline software: ZONE3, MeasureMind 3D, Meaure-X

 Power Requirements

 100-120 VAC or 200-240 VAC, 50/60 Hz, 1 phase, 700W

 Operating Environmnet, Safe Operation

 Temperature 15-30 °C,

 Rated Environment

 Temperature 18-22 °C, stable to ±1 °C, max rate of change 1 °C / hour, max vertical gradient of 1 °C / meter; 30-80% humidity; vibration <0.001g below 15 Hz
